6AV6643-0CD01-1AX0 Touch screen glass panel

group nameSimatic Multi Panel
Min Order1 piece
brand nameVICPAS
model6AV6643-0CD01-1AX0
payment methodWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
update timeTue, 05 Nov 2024 02:21:55 GMT

contact supplier

Paramtents

Brand Siemens
Line Multi Panel MP277 10.4''
Warranty 365 days
Status In Stock
Size 10.4 inch
Model 6AV6643-0CD01-1AX0
Accessories Touchscreen, lcd display, protective film, plastic case

Packging & Delivery

Min Order1 piece

Briefing

Siemens MP277 Touch Accessories, Touch, Overlay, LCD, Plastic Case. 365-day Warranty-Fully Tested-Factory Prices-Fast Shipping.

Detailed

6AV6643-0CD01-1AX0 Siemens MP277 10.4'' Touchscreen Panel Glass, Protective Film, LCD Display and plastic case for Repair Replacement

Order each part separately is available

6AV6643-0CD01-1AX0 Touchscreen Panel Glass, Protective Film, LCD Display, Plastic Cover Body, LCD Screen, Power Supply Connector, LCD Gasket, LCD FPC, Case Gasket, Mounting Clips Repair Replacement

The Multi Panel MP 277 6AV6643-0CD01-1AX0 units are an extension of the 270 series.The HMI devices are based on the innovative standard operating system, MicrosoftWindows CE 5.0. The Multi Panel MP 277 units belong to the "Multifunctional Platform" product category. The HMI devices offer enhanced communication options to the office world. The Pocket Internet Explorer is already installed on the HMI devices.
The MP 277 offers a variety of application uses, high performance and a favorable cost/performance ratio.

The devices are equipped with:
● PROFIBUS port
● Ethernet port for connection to PROFINET
● 2 USB ports
● TFT screen with up to 64k color

Thanks to the wide range of devices, you get to use the device that is suited to you.
In addition to the classic HMI application WinCC flexible, the HMI devices also support additional applications, for example:
● Sm@rtService
● Sm@rtAccess
● OPC server

VICPAS supply 6AV6643-0CD01-1AX0 Siemens MP277 10" touch panel, overlay, LCD FPC, Mounting Clips, Power Supply Connector, LCD Display, Case Gasket, LCD Gasket, plastic case. All of them with VICPAS 365 days warranty and support Urgent Worldwide Shipping.

The HMI device MP 277 10" Touch 6AV6643-0CD01-1AX0 is available in two enclosure models with differentproduct versions. The product version is indicated on the back of the HMI device.
SIMATIC MP 277 10" Touch Multi Panel with retentive memory 10.4" TFT display 6 MB configuration memory configurable with WinCC flexible 2005 Standard SP1.

Contact Best Price

Specifications:

The table below describes the parameters of the 6AV6643-0CD01-1AX0 Siemens MP277 HMI Parts.

Part Number :	6AV6643-0CD01-1AX0
Screen diagonal:	10.4 in
Design of display:	TFT
Warranty:	365 days Warranty
Product Line:	Siemens MP277 10

Active power input, typ.:	12 W
MTBF backlighting (at 25 °C):	50 000 h
Number of colors:	65 536
Mounting position:	vertical
Type of supply voltage	DC

Related Simatic MP277 10 Part No. :

Siemens Multi Panel MP277 10	Description	Inventory status
6AG1643-0CD01-4AX0	MP277-10	In Stock
6AG1643-0CD01-4AX1	MP277-10	Available Now
6AV6643-0CD01-1AX0	MP277-10	In Stock
6AV6643-0CD01-1AX1	MP277-10	In Stock
6AV6643-0CD01-1AX2	MP277-10	In Stock
6AV6643-0CD01-1AX5	MP277-10	In Stock
6AV6643-0ED01-2AX0	MP277-10	Available Now
6AV6643-5CD30-0YA0	MP 277 10" TOUCH	In Stock
6AV6643-7CD00-0CJ0	MP 277 10" TOUCH	Available Now
6AV6643-7CD00-0CJ1	MP 277 10" TOUCH	In Stock
6AV6643-8AD10-0AA0	SIMATIC MP 277 10" TOUCH	In Stock
6AV6643-8AD10-0AA1	MP 277 10" TOUCH SMALL FRAME	In Stock
6AV6652-3PB01-0AA0	MP277 10	Available Now
6AV6652-3PB01-2AA0	MP 277 10	In Stock
6AV6652-3PC01-1AA0	MP 277 10	Available Now
6AV6652-3PD01-1AA0	SIMATIC MP 277 10" TOUCH	Available Now
SIMATIC Multi Panel	Description	Inventory status

Siemens MP277 HMI Manuals PDF Download:

6AV6643-0CD01-1AX0 Siemens MP277 10 datasheet pdf

Siemens Simatic MP277 Panel manual

FAQ:

Question: What is the 6AV6643-7CD00-0CJ0 Siemens MP277 HMI parts price?

Answer: Submit a fast quote, send VICPAS an email for best price.

Question: Design of the HMI Device MP 277 10" Touch 6AV6643-7CD00-0CJ0 Panel

Answer:Front view and side view:

Front view and side view: 6AV6643-0CD01-1AX0 Siemens

① Slot for a memory card
② Display / touch screen
③ Oblong holes for mounting clamps
④ Mounting seal

Bottom view:

6AV6643-0CD01-1AX0 Siemens MP277 10Bottom view

① Interfaces
② Oblong holes for mounting clamps
Rear view:

① Rating plate
② Slot for a memory card
③ DIP switch
④ Interface name
⑤ Fixing elements for strain relief

Question: How to use Siemens MP277 10 touch operating a project?

Answer:Configuration and process control phase:
HMI devices can be used to operate and monitor tasks in process and production automation. The plant screens on the HMI devices are used to provide a clear overview of the active processes.
The HMI device project, which includes the plant screens, is created during the configuration phase. The configuration engineer defines which tasks the HMI device has in the process and defines the following in detail:

● Which process data is displayed on the individual HMI device
● Which plant components are controlled by this HMI device

The configuration engineer stores this information in the project's screens. The project is transferred to the HMI device during commissioning.
After transfer to the HMI device, current processes can be operated and monitored in the project's screens. The screens enable you to observe, for example, operational states, current process data and faults in a plant.
Operating elements which are used to operate the process, for example buttons, I/O fields and alarm windows, are displayed in the screens.

Operator control options
The hardware of the HMI device determines which of the following operator control optionsare available:

● Touch screen
The operating elements shown in the dialogs are touch-sensitive. Touch objects arebasically operated in the same way as mechanical keys. You activate operating elementsby touching them with your finger. To double-click them, touch an operating elementtwice in succession.

● HMI device keyboard

The operating elements shown in the screens are selected and operated using the keysof the HMI device.

● External keyboard, connected via USB

● External mouse, connected via USB
