ESA IT Text HMI IT105BK101 Membrane Keyboard Replacement
group nameIT Touch
-
Min Order1 piece
brand nameVICPAS
modelIT105BK101
payment methodWestern Union, T/T, PayPal, Credit Card
-
update timeSun, 03 Nov 2024 03:31:47 GMT
Paramtents
Brand ESA
Size 5.7 inch
Warranty 180 Days
Product Line IT Series
Supply IT105BK Membrane Keypad
Packging & Delivery
Min Order1 piece
Briefing
Detailed
ESA TEXT HMI IT105BK101 Membrane Keyboard Replacement
IT Series IT105BK101 HMI, 5.7" 16 Tones of Blue (STN), Keyboard, 1x Serial Port RS232/485/MPI, USB, 1x Ethernet Port, 1x SD/MMC
The VESA industrial PC is the ideal solution to overcomeconstraints caused by limited space for the installation of a PanelPC on a machine. ESA Industrial TERMINAL (IT) is a device that allows the user to control orsimply monitor a productive process. It can send commands using configuredby the user; it can send data determining the process on hand andcan display information deriving from the productive process. The informationcan be in the form of an Alarm, an Information (Info-) Message or inbinary data format.
VICPAS supply ESA IT TEXT HMI IT105BK101 membrane switch with 6 months warranty and support Urgent Worldwide Shipping.
Specifications:
The table below describes the parameters of the ESA IT105BK101 HMI Parts.
| Brand: | ESA |
| Display Type: | Graphic LCD monochrome STN |
| Resolution: | 320x240 |
| Warranty: | 6-Months Warranty |
| Product Line: | IT TEXT |
| Display Type: | LCD TFT |
| Display area size: | 4.85x2.68 |
| Columns by Rows: | Depending on used Font |
| Input voltage: | 18 - 32 V DC |
| Part Number: | IT105BK101 |
Related ESA IT105BK Part No. :
| ESA IT105BK | Description | Inventory status |
| IT10500P0 | ESA IT Text HMI IT105BK131 Membrane Keypad Replacement | In Stock |
| IT1050000 | ESA IT Text HMI IT105BK121 Membrane Keyboard Replacement | In Stock |
| IT10500P0 | ESA IT Text HMI IT105BK111 Membrane Switch Replacement | In Stock |
| IT10500P0 | ESA IT Text HMI IT105BK101 Membrane Keyboard Replacement | In Stock |
| ESA VT TEXT | Description | Inventory status |
ESA IT105BK101 Operator Panel HMI Manuals PDF Download:
FAQ:
Question: How to adjust the contrast on the ESA IT105BK101 Display?
Answer:To improve the quality of the representation on the display it may be necessaryto adjust its contrast. This can be done by rotating the trimmer (C) atthe back of the VT ; turn it (using a small screwdriveror a trimmer tool) in one direction and, if the display quality worsens,turn it the other way.
Question: What is the IT105BK101 Termination of CAN line?
Answer:The VT in question integratesthe termination resistances of the serial line (typically 120 ohms)which can be inserted by means of a jumper (preset on 1-2, line not terminated).To activate the termination:
• Make sure the device is not connected to the power supply.
• Remove the cover.
• Identify the jumper unit J2.
• Position the jumper between pins 2 and 3 (line terminated).
• Replace the back cover.
• Reconnect the power supply.
Question: What is ESA IT105BK101 mebrane keyboard HMI parts price?
Answer: Submit a fast quote, send VICPAS an email for best price.
Common misspellings:
I105BK101IT05BK101
IT15BK101
IT10BK101
IT105K101
