Refrigerated air compressor air dryer for screw air compressor

Technical Specifications

●  Refrigerated air compressor air dryer

 ● Pressure range: 0.6-1.6 Mpa

●  Max air inlet temp.: 60 Deg C

●  Max ambient temp.: 50 Deg C

●  Max cooling water inlet temp.: 38 Deg C

●  Cooling method: air cooled type / water-cooled type

●  Pressure dew point: 2-10 Deg C

●  Power: 220/380V-1PH-50HZ

●  Refrigerant: R-22 (R-407C, R-134A as optional)

 Note: Refrigerated air compressor air dryer without metal box board for over 80 m3/ min. Other special standards can be customized.

Main Components

Compressor:Copeland,Bitzer or Performer

Heat exchanger:Aluminum plate fin type

Expansion Valve:Danfoss

By Pass Valve:Danfoss

Auto Drainer:Electronic Drainer

Working Principle

Refrigerated air compressor air dryer makes the water vapor in the compressed air condenses into droplets through cooling so as to achieve the

purpose of reducing moisture content. Condensed droplets are discharged by the automatic drainage system.

Annotation:

Performance Parameters

Company Information

● Hangzhou Shanli Purify Equipment Corp., was formed in 1997, as a  Refrigerated air compressor air dryer company.

● The workshop at integrated engineers and contractors has a dedicated team, which is continuously engaged in

   upbringing of new technologies for greater efficiency.

● The company was involved in supplying of  Refrigerated air compressor air dryer as a manufacturer, exporter and supplier.

Why to chose Shanli?

1. Quality:

● Certification: CE, ISO-9001, ISO-14001 and 26 patents to ensure unmatched quality of our product assortment.

● Stringent quality control mechanism: updating the involved technology as per prevailing international standards;

● Stable performance: using premium grade raw material from highly reputed manufacturers, like Danfoss, Emerson, Performer,

   Bitzer, Fusheng, Sprolan;

2. Customer:

● Some of major cooperated customers (from our wide range of customers ) have been enlisted below for reference:

3. Scale:

● Shanli purify has become one of  largest manufacturers in purifying industry of China with annual sales turnover USD 22 million.

● Shanli air dryer has a wide range of customers who have full faith in our service delivery, warranty, quality and workmanship.

4.Comprehensive Product Line

  Refrigerated air compressor air dryer

Shanli supply air cooled refrigerated air compressor air dryer,water cooled refrigerated air compressor air dryer,normal temperature refrigerated air compressor air dryer and

high temperature refrigerated air compressor air dryer.

Desiccant Air Dryer

Shanli provide Heatless adsorbent air dryer,heated adsorption air dryer,Heat of Compression desiccant air dryer and

Blower Purge adsorption air dryer.

Energy ‐ saving Products

It includes Zero purge Heat of Compression adsorption air dryer,Zero purge Blower Purge desiccant air dryer and

Combined type air dryer

Other Products

This series include Pre-cooler machine, Water chiller, Heat recovery unit for air compressor, air Filter and air filter element.

5.Technical Force

Technical research and development capabilities: 35 R& D personnel, including five senior engineers, 12 engineers, 18

assistantengineers. (Innovation) Award Fund has set up, the company so far has 30patents.

Product Applications

There are still some areas and applications where Shanli air dryers can be used, such as power construction, packing food,

making ship, cleaning medical molding,removing EDM recast and discoloration, finishing and texturing injection mold cavities,

cleaning orifices in turbine blades,engraving optical lenses,cleaning and preparation of semi-precious stones and jewelry, etc.

Package and Shipment

● Packing details: Wooden crate pallet plus foam board and bubble film, Full closed wooden case. 1pcs/each package

   (for stationary desiccant air dryer)

● Transportations: sea transport,  rail transport, air transport, road transport, LCL/ FCL container transport  or as requested

● Trade terms: FOB, CFR, CIF and EXW, DDP, etc.

● Delivery time: in 20 days after receiving deposit (customized machines not included)
