High-Speed Single Crank Press Punch Machine for High Speed Stamping

group nameHigh Speed Punch Press Machine
Min Order1 piece
brand nameFANTY -Steel Coil Handling Equipment Manufacturer
modelD1G Series High-Speed Single Crank Press Machine
payment methodL/C, Western Union
update timeFri, 08 Nov 2024 21:38:00 GMT

contact supplier

Paramtents

Color Standard white (other colors are available)
Payment 30% T/T as deposit, rest against shipping
Customized Service Yes

Packging & Delivery

Min Order1 piece

Briefing

As the punch press machine, this Single Crank hydraulic press machine is designed for fast and efficient metal forming.

Detailed

Description of High-Speed Single Crank Punch Press Machine

The High-Speed Single Crank Punch Press is a specialized hydraulic press machine designed for high-speed stamping applications. This punch press machine features a single crank mechanism that optimizes speed and efficiency, making it ideal for high-speed production environments. Equipped with precision press punches and punch press dies, the machine ensures accurate and consistent punching operations. Its robust construction and advanced design enable it to handle various materials and thicknesses with ease. The punch press machine is engineered to deliver rapid punching cycles while maintaining high precision and reliability. As a key component in high-speed stamping lines, the Punch Press Machine enhances productivity and reduces cycle times, making it a valuable asset for modern manufacturing operations. Overall, the Punch Press Machine provides a reliable and efficient solution for high-speed punching applications, offering exceptional performance and durability in stamping processes.

High-Speed Single Crank Press Machine for High Speed Stamping

This press utilizes a single crank mechanism to deliver high-speed and precise performance. It is capable of achieving rapid stroke rates, significantly reducing cycle times and increasing production output. The press offers excellent responsiveness and accuracy, allowing for precise control over the forming process. Its robust construction ensures durability and reliability, even under heavy-duty usage.

Features of High-Speed Single Crank Punch Press Machine

● Capacity range: 80～200 tons

● Rated Tonnage Point: 2 or 3

● Stroke Length (mm): 30

● Die height (mm): 360 or 400

● Slider Adjustment (mm): 50

Specification of High-Speed Single Crank Punch Press Machine

Model	D1G-80	D1G-125	D1G-160	D1G-200
Capacity (tons)	80	125	160	200
Rated Tonnage Point	2	3	3	3
Stroke Length (mm)	30	30	30	30
Number per minute (S.P.M)	160-280	160-240	160-220	150-200
Die height (mm)	360	400	400	400
Slider Adjustment (mm)	50	50	50	50
Bolster Area (mm)	900x500	1100x600	1300x700	1300x800
Bolster Thickness (mm)	130	160	180	200
Slider Area (mm)	800x450	1000x550	1200x600	1200x600
Height of the top surface of bed from floor level (LRxFB)	505x380	550x450	550x450	625x550
Main Motor(kw)	11	18.5	22	30

Stamping Products of High-Speed Single Crank Punch Press Machine

Stamping Products of High-Speed Single Crank Press Machine

Application of High-Speed Single Crank Punch Press Machine

The high speed single crank Press is suitable for various applications, including stamping, blanking, and piercing, making it an ideal choice for industries such as automotive, electronics, and appliance manufacturing. Experience enhanced productivity and superior performance with our state-of-the-art Single Crank High Speed Press.

Company Details

Fanty factory produces decoiler, feeder and press machines

Fanty machinery focus on the domestic market of punch press automation equipment production and sales from 2013. The field including domestic hardware industry , automotive stamping line, auto metal stamping part, saw blade production, high speed rotor and stator stamping and lamination, eyelet stamping line and so on.

We provide high quality uncoiling, leveling, feeding and punch equipment to help many local factories realize the importance of automation production, and more and more factories upgrade and improve their metal stamping line. Fanty machinery has exported machine to more than 30 countries. MORE

FAQ

Q: How is your high speed single crank press punch machines warranty service?

A: We provide 1 year warranty since the delivery date for high speed single crank press punch machine.

Q: Can your high speed single crank press punch machines handle different types of materials such as stainless steel and aluminum?

A: Absolutely! Our high speed single crank press punch machine is designed to handle a variety of materials, including stainless steel, aluminum, mild steel, and more. The versatility of our machines allows for efficient and precise punching of different material types.

Q: Do you provide after-sales support and maintenance services for your high speed single crank press punch machines?

A: Yes, we take pride in offering comprehensive after-sales support and maintenance services for our high speed single crank press punch machine. Our dedicated team of technicians is available to provide technical assistance, conduct routine maintenance, and address any issues that may arise during the lifespan of the machines.

Q: Can your high speed single crank press punch machines be customized to meet specific production needs?

A: Certainly! We understand that different customers may have unique production requirements. Our high speed single crank press punch machine can be customized to accommodate specific needs such as special tooling, automation integration, or unique punching patterns. Our experienced engineering team will work closely with you to provide tailored solutions.
