2.9 inch Intelligrated Pick to Light Wireless E paper ESL Digital Warehouse Order Picking Label

group namePick to Light Electronic Label
Min Order1 piece
brand nameSertag Pick to Light System Manufacturer
modelPick to Light SETP_Label_V23(Battery Powered)
payment methodT/T
update timeFri, 08 Nov 2024 12:06:27 GMT

contact supplier

Paramtents

Screen Material 2.9 inch E-paper Display
Dimension 156x48x20mm
Button 4 Buttons
Indicator Light 4 RGB Lights
Power Supply Battery (AA Battery*4)
Communication Mode Wireless
Feature It can display text and pictures, low power
Application Factory, Warehouse, E-commerce, Logistics...

Packging & Delivery

Min Order1 piece

Briefing

Put by light system, 2.9 inch e-paper screen, battery powered, supports text/picture/barcode/QRcode, for smart warehouse.

Detailed

Pick to Light System in Manufacturing SETP_Label_V23(Battery Powered) Description

2.9 inch Intelligrated Pick to Light Wireless E paper ESL Digital Warehouse Order Picking Label

Discover the future of warehouse optimization with SETP_Label_V23 (Battery Powered), a cutting-edge pick to light system designed to streamline picking processes. This innovative solution employs a 2.9-inch electronic paper screen, complemented by three small buttons and a prominent LED-enabled large button, ensuring swift and accurate operations in pick-to-light warehouses.

Powered by long-lasting batteries, exceeding a remarkable 3-year lifespan, SETP_Label_V23 promises unparalleled reliability and efficiency. Its rapid response time and stable performance eliminate screen flickering, enhancing user experience in pick-to-light warehouse environments.

Pick to Light System in Manufacturing SETP_Label_V23(Battery Powered) Specification

Model	SETP_Label_V23(Battery Powered)	Working Temperature	0~50℃
Power Supply	Battery (AA Battery*4)	Operating Frequency	868MHz
Dimension	156x48x20mm	Viewing Angle	Nearly 180°
Screen Size	2.9 inch	Displayable content	Text/Picture/Barcode/QRcode
Resolution	296*128	Battery Lifetime	>3year (10 times per day)
Display Technology	Full Graphic E ink Display	Communication Mode	Wireless
Pixel Color	Black & White	Extended Interface	1 input pin
Case Color	White & silver gray	Compliance	CE, RoHS
Button	4 Buttons	Wireless Firmware Update	Yes
Indicator Light	4 RGB Lights	Template design DIY	Yes
LED Color	7Colors(Red/Green/Blue/Yellow/purple/white/cyan)	Communication equipment	Controller: SETP_ Router_V1.4/ SETP_ Router_V1.2

Pick to Light System in Manufacturing SETP_Label_V23 Installation Method

The SETP_Label_V20 offers three convenient installation methods to adapt to diverse environments:

① Adhesive fixation for swift deployment

② Magnetic fixation for effortless repositioning

③ Track slot fixation (can be customized).

Purchasing Guide for the Base Stations of Pick to Light SETP_Label_V23(Battery Powered)

1. SETP_Router_V1.4 Base Station:

Recommend！

Features: Equipped with a built-in server program for effortless data transmission.

Ease of Use: Users simply send operational instructions directly to this base station for efficient data transfer, ensuring user-friendly functionality.

2. SETP_Router_V1.2 Base Station:

Functionality: Facilitates instruction transmission via PC or scanner.

Operation: Functions by relaying instructions from the PC or scanner through the SETP_Router_V1.2 base station to control LED lights/screens on the pick-to-light system.

Pick to Light System in Manufacturing SETP_Label_V23(Battery Powered) Advantage

Cutting-Edge Display Technology

The 2.9-inch E-Paper Display showcases exceptional efficiency with ultra-low power consumption, ensuring prolonged performance without screen flickering. This feature guarantees consistent operations, promoting swift response times ideal for efficient pick-to-light systems.

Enhanced User Interface

Featuring a prominent, illuminated large-sized button, SETP_Label_V23 provides intuitive pick light support. This feature streamlines operations, making it effortless for users to identify and handle tasks within a pick-to-light system environment.

Exceptional Battery Life and Connectivity

Benefit from an extended battery life, exceeding 3 years, ensuring continuous, reliable performance in pick to light systems.

Operational Efficiency and Cost Reduction

The intuitive interface, complete with buttons and indicator lights, streamlines operations, optimizing speed and quality while reducing training time for operators within a pick to light system.

Tailored Solutions for Your Business

Bring us your ideas, and our dedicated team will work with you to create a bespoke pick-to-light solution that perfectly aligns with your operations. Our team ensures that the customized solution fits seamlessly into your existing setup, providing uninterrupted workflow efficiency.

Pick to Light System in Manufacturing SETP_Label_V23 Download

Pick To Light System-SETP_Label_V23

SETP_Label_V23 System Developer's Manual V1.2

Pick to Light Operation Manual

Pick to Light System in Manufacturing Application
